How to Parse XML Documents in Elixir

Maximilian Störchle

August 27, 2018

As software engineers, we often have to deal with different document formats. One example of such a document format is XML(opens in a new tab). This blog post will be a short introduction on how to parse XML(opens in a new tab) documents with Elixir(opens in a new tab), and it includes an example of how it’s done.

Example

First, we need to create the example. For this, run the following command to create a new Elixir(opens in a new tab) project called xml_example, and navigate into the project’s directory:

mix new xml_example
cd xml_example

We also need an example XML(opens in a new tab) file to parse. We create an XML(opens in a new tab) document in the root of our example directory with the following content and name it example.xml:

<todos>
  <todo id="1">
    <body>This is the body of to-do item #1</body>
    <priority>3</priority>
  </todo>
  <todo id="2">
    <body>This is the body of to-do item #2</body>
    <priority>1</priority>
  </todo>
  <todo id="3">
    <body>This is the body of to-do item #3</body>
    <priority>3</priority>
  </todo>
</todos>

This XML(opens in a new tab) document consists of a root node, todos, which should model a to-do list. Each todo item has the item id as an attribute and the priority of that to-do as a subnode.

After creating this example document, we can start Elixir’s(opens in a new tab) interactive shell(opens in a new tab) so that we can play around with the example document:

iex -S mix

The first thing we have to do in order to parse the file is to open it:

{:ok, xmldoc} = File.read(Path.expand("./example.xml"))

xmerl

xmerl(opens in a new tab) is a library for parsing XML(opens in a new tab) documents in Erlang(opens in a new tab), and since Elixir(opens in a new tab) is built on top of Erlang(opens in a new tab), we can use it for our example. But because xmerl(opens in a new tab) is an Erlang(opens in a new tab) library, we need to take care of a few things, such as parsing the input to a charlist(opens in a new tab). To parse the XML(opens in a new tab) document with xmerl(opens in a new tab), run the following expression in the interactive shell(opens in a new tab):

{doc, []} = xmldoc |> to_charlist() |> :xmerl_scan.string()

ℹ️ Note: Don’t use the :xmerl_scan.string/1 function on untrusted input (e.g. data coming in an HTTP request), as it may cause atom table exhaustion, which will make your application crash. You can read more about this vulnerability in the EEF Security Working Group recommendations(opens in a new tab).

This will convert the content of the document we previously read to a charlist(opens in a new tab) with to_charlist/1 and then parse it with :xmerl_scan.string/1. This function will return a tuple, where the first element is the parsed content represented in xmerl(opens in a new tab) records (Erlang records(opens in a new tab) defined in xmerl/include/xmerl.hrl). The second element will be a charlist(opens in a new tab) of the rest of the input that could not be parsed. In our case, :xmerl_scan.string/1 should be able to parse the entire input; that’s why we match an empty list to the second element in the returned tuple. This is how the return value of this function will appear:

{{:xmlElement, :todos, :todos, [], {:xmlNamespace, [], []}, [], 1, [],
  [
    {:xmlText, [todos: 1], 1, [], '\n  ', :text},
    {:xmlElement, :todo, :todo, [], {:xmlNamespace, [], []}, [todos: 1], 2,
     [{:xmlAttribute, :id, [], [], [], [todo: 2, todos: 1], 1, [], '1', false}],
     [
       {:xmlText, [todo: 2, todos: 1], 1, [], '\n    ', :text},
       {:xmlElement, :body, :body, [], {:xmlNamespace, [], []},
        [todo: 2, todos: 1], 2, [],
        [
          {:xmlText, [body: 2, todo: 2, todos: 1], 1, [],
           'This is the body of todo item #1', :text}
        ], [], '/Users/max/Documents/pspdfkit/xml_example', :undeclared},
       {:xmlText, [todo: 2, todos: 1], 3, [], '\n    ', :text},
       {:xmlElement, :priority, :priority, [], {:xmlNamespace, [], []},
        [todo: 2, todos: 1], 4, [],
        [{:xmlText, [priority: 4, todo: 2, todos: 1], 1, [], '3', :text}], [],
        '/Users/max/Documents/pspdfkit/xml_example', :undeclared},
       {:xmlText, [todo: 2, todos: 1], 5, [], '\n  ', :text}
     ], [], '/Users/max/Documents/pspdfkit/xml_example', :undeclared},
     ...

Manually Parse xmerl Records

Because the returned data structure consists of Erlang records(opens in a new tab), which are defined in xmerl/include/xmerl.hrl, we have to convert them to Elixir records(opens in a new tab) to be able to use them efficiently in Elixir(opens in a new tab). For this, we’ll use the defrecord macro(opens in a new tab), which we have to put into a module. We call this module XML, and we also define a few helper functions for parsing the XML file:

defmodule XML do
  import Record
  defrecord(:xmlElement, extract(:xmlElement, from_lib: "xmerl/include/xmerl.hrl"))
  defrecord(:xmlAttribute, extract(:xmlAttribute, from_lib: "xmerl/include/xmerl.hrl"))
  defrecord(:xmlText, extract(:xmlText, from_lib: "xmerl/include/xmerl.hrl"))

  def get_child_elements(element) do
    Enum.filter(XML.xmlElement(element, :content), fn child ->
      Record.is_record(child, :xmlElement)
    end)
  end

  def find_child(children, name) do
    Enum.find(children, fn child -> XML.xmlElement(child, :name) == name end)
  end

  def get_text(element) do
    Enum.find(XML.xmlElement(element, :content), fn child ->
      Record.is_record(child, :xmlText)
    end)
    |> XML.xmlText(:value)
  end
end

require XML

This enables us to get the data we want out of the XML(opens in a new tab) document. For example, we can get a list of all to-do bodies, like this:

doc |> XML.get_child_elements() |> Enum.map(fn todo -> XML.get_child_elements(todo) |> XML.find_child(:body) |> XML.get_text() end)

# Returns:
['This is the body of to-do item #1',
 'This is the body of to-do item #2',
 'This is the body of to-do item #3']

Although it is possible to get the data we want out of the document using the above, this looks like a lot of code. There must be a more convenient way to query data out of xmerl(opens in a new tab)’s data structure.

XPath

XPath(opens in a new tab) is a query language for selecting nodes in an XML document. xmerl(opens in a new tab) supports querying an XML(opens in a new tab) document with XPath(opens in a new tab). Using this query language, we can rewrite our code to query the text of all to-do bodies:

:xmerl_xpath.string('/todos/todo/body/text()', doc) |> Enum.map(&XML.xmlText(&1, :value))

We can also get rid of all the helper functions we defined in our XML module, as we won’t need them. This is because we can query the XML document with XPath(opens in a new tab) instead of manually parsing the document.

Using XPath(opens in a new tab), we’re also able to choose nodes based on more complex queries, like selecting nodes based on attributes or on matching child nodes — for example, when we want to get the body text of all to-dos where the ID attribute is 1:

:xmerl_xpath.string('/todos/todo[@id=\"1\"]/body/text()', doc) |> Enum.map(&XML.xmlText(&1, :value))

# Returns
['This is the body of to-do item #1']

Another example of where we want to get the body text of all to-dos is where a child node “priority” with the value 3 exists:

:xmerl_xpath.string('/todos/todo[priority=\"3\"]/body/text()', doc) |> Enum.map(&XML.xmlText(&1, :value))

# Returns
['This is the body of to-do item #1', 'This is the body of to-do item #3']

SweetXML

Another option for parsing XML(opens in a new tab) documents with Elixir(opens in a new tab) is using the SweetXML(opens in a new tab) library, which is a small wrapper around xmerl(opens in a new tab) that reduces the boilerplate code we have to write for converting the input to a charlist(opens in a new tab) or converting the xmerl(opens in a new tab) records.

In order to use the SweetXML(opens in a new tab) library, we have to quit our interactive shell(opens in a new tab) session and add SweetXML(opens in a new tab) to the dependencies list in mix.exs. Then we run mix deps.get in the project’s root directory to download the dependencies:

defp deps do
  [
    {:sweet_xml, "~> 0.6.5"}
  ]
end

After we have downloaded the dependencies, we can run iex -S mix to start another interactive shell(opens in a new tab) session.

Now we can run the same queries, like in our previous example, but with even less code:

import SweetXml
{:ok, xmldoc} = File.read(Path.expand("./example.xml"))

# get body text of all to-dos where the ID attribute is `1` as a list:
xmldoc |> xpath(~x"/todos/todo[@id=\"1\"]/body/text()"l)

# Returns
['This is the body of todo item #1']

# get the body text of all to-dos where a child node "priority" with the value `3` exists as a list:
xmldoc |> xpath(~x"/todos/todo[priority=\"3\"]/body/text()"l)

# Returns
['This is the body of to-do item #1', 'This is the body of to-do item #3']

SweetXML(opens in a new tab) defines a custom ~x Sigil(opens in a new tab), which also lets you define the return values in addition to the XPath(opens in a new tab) query. The syntax for the custom Sigil(opens in a new tab) looks like this, ~x"/some/xpath/query"l, where the last character (l in our example) represents the return value. l stands for list, but you can also choose other return values like i for integer, s for strings, and more. Take a look at the SweetXML documentation(opens in a new tab) to see all available options.

Conclusion

Although xmerl(opens in a new tab) can be used directly from Elixir(opens in a new tab), I recommend SweetXML(opens in a new tab) for parsing XML(opens in a new tab) documents, because it’s easier to use. The custom Sigil(opens in a new tab) to define the return value is also a nice feature. All in all, it’s nice to have such a mature ecosystem provided by Erlang(opens in a new tab).

This post was updated in July 2020 to point out a vulnerability in xmerl.
