A pragmatic cross-platform approach

At Nutrient we offer native SDKs for iOS, Android and soon also for the browser. Yet, invisible to the user, all share a large part of the codebase. This wasn’t always the case. Here’s what we learned over the last few years.

Humble beginning

Nutrient started in 2010 as an iOS-only project. Back then there was just one person working on it. 6 years later, we’re 28 people, have frameworks for iOS, Android and the Web, and our core framework even runs on OS X and Windows.

In 2014 when we started working on our Android SDK, the existing codebase was a mix of Objective-C and C (for the performance critical parts), and it was highly dependent on Apple’s Core Graphics PDF renderer. We had to start fresh for Android — yet it was clear that we couldn’t afford to maintain two completely separate codebases: this would simply not scale. As a small, bootstrapped company we had to find an approach where we can re-use most of our codebase.

Choosing the right strategy

Everyone knows that cross-platform is hard — furthermore many applications that are cross-platform ultimately deliver a sub-par experience on all platforms. One of the main selling points of our SDK is that it’s really native and feels at home on the platform, like something Apple or Google would put on there. Compromising on this experience was not an option.

There are various projects that try to abstract the user interface across multiple platforms for apps, such as Xamarin.Forms, Apache Cordova or — very promising — Facebook’s React Native. We have some experience with all of them, as we offer libraries that make it simpler to use and configure Nutrient within these products. Yet for an SDK, none of these solutions work. They are all more or less compromises and also incur overhead and additional complexity. At least the UI-part had to be native to the platform.

A perfect candidate for a shared module is the PDF renderer. We actually wanted to go further and share licensing, parsing, networking and most of our business logic. Initially, we flirted with the idea of using Apportable to cross-compile existing code to Android, however after an initial chat it was clear that their service is more tailored to games, and many of the frameworks we use were missing from Android or incomplete. There were also obvious licensing questions and worries about betting so heavily on a company that is VC-backed. In the end they didn’t even send us their SDK to evaluate, so we quickly moved away from that idea. In retrospect, this was great, since while Apportable would have helped us to get to Android faster, we would be stuck again when porting code to Linux for Nutrient Web SDK.

Choosing the right language

With Objective-C out of the question, C or C++ where pretty much the only languages that were worth considering that could be compiled to any platform. Lua didn’t feel powerful enough for a project of our size, and Swift isn’t mature enough yet, even though work is underway to bring it to Android and make it easier to use as a server language. There are projects such as RoboVM that run Java on iOS or even scarier solutions such as j2objc that cross-compile Java source code to Objective-C sources, however this adds a lot of complexity and again would be a vendor lock-in. JavaScript is something to consider as it has a powerful ecosystem and there are many interpreters available that make it almost as flexible as C++. However, parsing and rendering performance is a major factor for us and it’s still significantly slower than C++, plus one has to pay a startup tax while it’s being parsed.

C++ is a pragmatic solution and a first-class citizen on almost every platform. Furthermore, we were intrigued by the advances of C++ in form of C++ 11, 14 and 17. Many major projects that we use every day are built in C++: WebKit, Clang — even Swift itself. There’s great support for it on iOS: Objective-C and C++ can be freely mixed, and Google offers an NDK that makes it relatively simply to build native libraries for Android.

Especially for Android, there are also quite some downsides compared to pure Java or even JavaScript. Adding a native library greatly increases complexity and compile times, and also makes you think about which platforms should be supported. There’s also the problem of debugging: while Android Studio has made some steps in that direction, there’s still no way to see a stack trace from Java down to your C++ code. You’re basically left with old-school printf() debugging.

Android inception

As a PDF library, our requirement in the beginning were mostly to parse data fast, and then bring them from C++ to Java. Think about page links, outlines, page labels, page sizes, images and so on. Java uses a bridge called Java Native Interface (JNI) to bring managed code to native code and vice versa, and everyone who wrote such code before knows that it’s painful. We started using Google’s FlatBuffers to automatically marshal data structures in C++, pack them up, send them as one junk to Java and then unpack them there to limit our JNI surface area. This turned out to work great and is really fast. Flatbuffers includes a code generator that generates all the marshaling code from a schema. It’s also a mature and widely used project, so it was quite easy to integrate.

Moving the iOS SDK to C++

After we’ve shipped Android 1.0, we started thinking about how we can move our iOS SDK over to use the new ‘PSPDFCore’, as it is called internally. The goal was to change as little public API as possible. However we didn’t want to expose any C++ to our customers. One of our goals is to deliver a product with an API that feels just like the system APIs. Using C++ would require knowledge that not every iOS developer has. It would also create an API that you cannot use from Swift, so that’s out of the question.

Luckily, around that time Dropbox announced Djinni. Djinni is an IDL that creates boilerplate code for you. You define your model and interface in this little language, and the djinni parser builds C++, Java and Objective-C++ boilerplate that translates between the languages.

Here are some examples:

OutlineElement = interface +c {
    const get_level(): i64;
    const get_action(): optional<Action>;
    const get_title(): string;
    const get_children(): list<OutlineElement>;
    const get_color(): optional<Color>;
    const is_bold_style(): bool;
    const is_italic_style(): bool;
}

OutlineParser = interface +c {
    const get_outline(): optional<OutlineElement>;
}

The get_color() call returns a Color object. In C++ we represent Color as a class. In Java we just want to use int since that’s a common pattern on Android and reduces the workload on the garbage collector. And for Objective-C/Swift on iOS, we’d want to use UIColor. By default, Djinni would create a PDFCColor class however, and a Color class on Java. But we can go one step further and create custom bridged data types as well:

---
name: Color
typedef: 'record'
params: []
prefix: ''
cpp:
  typename: 'PDFC::Color'
  header: '"Basic/Color.hpp"'
  byValue: false
objc:
  typename: 'UIColor'
  header: '"PSPDFEnvironment.h"'
  boxed: 'UIColor'
  pointer: true
  hash: '(NSUInteger)%s'
  printDescription: '%s'
objcpp:
  translator: '::djinni::Color'
  header: '"Basic-objc.hpp"'
java:
  typename: 'int'
  boxed: 'java.lang.Integer'
  reference: true
  generic: false
  hash: '%s.hashCode()'
jni:
  translator: '::djinni::Color'
  header: '"Basic-jni.hpp"'
  typename: jint
  typeSignature: 'I'

In Nutrient we do this for many basic types such as Rect, Size, Point, Matrix and Color.

(As an aside, handling errors can understandably get somewhat tricky across platforms and languages. We discuss our approach to passing identifiable errors when using Djinni in our “Failable Methods with Djinni” blog post.)

Platform services

There are some features where the platform is much better than the C++ layer. It starts with simple things like receiving a low memory notification, showing an alert or even creating a thread or doing network requests. Often there are ways to do this in C++ as well, but they will involve more code, use less-tested paths or are just not possible (the alert). For that, we created an interface called NativeServices. This interface offers various other interfaces for specific tasks. We even went so far and bridged UnicodeServices to have regular expressions without having to ship libicu on Android.

# A place to initialize and retrieve native services.
NativeServices = interface +c {
	# initialize the NativeServices. If no UnicodeService is specified, we will try to pick an appropriate one. If no thread_service is specified, we will rely on a generic thread service that uses `std::thread`.
	static init(application_service: ApplicationService, unicode_service: optional<UnicodeService>, thread_service: optional<PlatformThreads>);

    # Retrieves native application services
    static get_application_services(): ApplicationService;

    # Retrieves the unicode service.
    static get_unicode_service(): UnicodeService;

    # Retrieves the thread service.
    static get_thread_service(): PlatformThreads;

    const low_memory_notification: string = "LowMemoryNotification";

    # Invoked from the native platform to inform about low memory warnings.
    static memory_notification(level: i32);
}

# This is a collection of methods that are very particular to a platform that can’t be easily
# implemented by the C++ core.
ApplicationService = interface +j +o {
    # Shows an alert
    show_alert(title: string, message: string, options: AlertOptions);

    # Checks if we're running in a simulator
    is_simulator(): bool;

    # Returns a temporary directory.
    temporary_directory(): string;
}

Right now most of our API is synchronous — designing API with callbacks is quite hard with djinni and something we’re still tinkering with.

Nutrient Web SDK

Now we mentioned that we reuse code even for Nutrient Web SDK, which runs in the browser. Indeed early experiments with emscripten worked well — we simply took our existing C++ core and compiled it to JavaScript. However, moving all processing to the client is not always a good idea. Our Web SDK will also run on smartphones and it should be fast — so instead we build a small wrapper around our core and created a command line interface which can render pages as images and emit JSON for model objects. Our C++ architecture even allows this to compile on Windows — so we’re extremely flexible in terms of backend platform.

Mistakes we made

Pretty early on we tried to add libdispatch into our C++ core, with the rationale that we can use the native GCD on iOS/Mac and ship our own copy of libdispatch on Android. libdispatch is open source and licensed under Apache 2.0 and there’s an extensive test suite, so this was pretty easy. It requires a compiler that understands the blocks syntax, so it forced us to use Clang on Android. It generally worked well, but caused major headaches with the Android debugging and instrumenting tools. It also made things tricky to compile for Windows, since libdispatch really was written for Unix and as such limits your portability. For a while we switched to the function-based methods but ultimately replaced this with boost::thread. The threads it creates are also problematic when you call up into Java-land with them. While there are ways to connect native threads to the garbage collector, Java really gets weird about this and much prefers threads that have been created in Java. The team at Dropbox recognized this as well and is calling up to Java-land for thread creation, much like we have our PlatformServices.

JNI calls are fairly expensive. Of course there’s data marshaling and that leads to various memory copying and initialization times, but that’s less of a problem on iOS. Android however pays a fairly high tax for JNI calls, and after every step the system requires one to check for pending exceptions. Djinni does a fairly good job of caching the expensive Java reflection part (since classes are looked up via strings), however there’s still some tax to pay. Designing APIs to move large chunks of data over in one call makes things more efficient, but might lead to additional shims or not great APIs in general. We ended up combining Djinni and Flatbuffers, depending on the data set to be both flexible and fast.

What’s next

Over the last two years we have built a strong, well-tested and powerful C++ project that can render PDFs with annotations and extract data. This project compiles on many platforms, including iOS, OS X, Android and less obvious ones like Windows or even the web. This foundation allowed to to ship our latest feature, the Document Editor to add, remove or rearrange pages on both iOS and Android at the same time.
