How to Flatten a PDF Using JavaScript

In this post, you’ll learn how to programmatically flatten PDFs in JavaScript using our Flatten PDF JavaScript API. With our API, you receive 100 credits with the free plan. Different operations on a document consume different amounts of credits, so the number of PDF documents you can generate may vary. All you need to do is create a free account to get access to your API key.

Flattening a PDF document is a common use case when working with PDFs and PDF forms. It’s especially crucial when preparing PDF files for printing. This is because PDFs often contain transparent layers that printers can’t detect (e.g. signatures, annotations, transparent objects). In such a case, printers will only print the visible layer. However, flattening a PDF will ensure that all layers are visible to the printer, because the Flatten PDF API will merge them into a single layer.

Additionally, some PDF viewers might not be able to display all types of PDF annotations, so flattening a PDF “bakes in” those annotations, ensuring they’re displayed accurately, regardless of the viewer.

Finally, and most importantly, you can flatten form fields to prevent users from editing or deleting the information input into a PDF form once it’s complete: After a PDF is flattened, the filled-in values will remain in the document, but users won’t be able to edit the fields.

Using PSPDFKit API will allow you to automate the process of flattening documents in your workflow.

PSPDFKit API

Document flattening is just one of our 30+ PDF API tools. You can combine our flattening tool with other tools to create complex document processing workflows, such as:

• Converting MS Office files and images into PDFs and then flattening them

• Merging several documents and then flattening the resulting document

• Adding watermarks and signatures to a document and then flattening them

Once you create your account, you’ll be able to access all our PDF API tools. It’s also important to note that all API tool combinations expend only one credit, which enables you to create complex workflows.

Step 1 — Creating a Free Account on PSPDFKit

Go to our website, where you’ll see the page below, prompting you to create your free account.

Once you’ve created your account, you’ll be welcomed by the page below, which shows an overview of your plan details.

As you can see in the bottom-left corner, you’ll start with 100 credits to process, and you’ll be able to access all our PDF API tools.

Step 2 — Obtaining the API Key

After you’ve verified your email, you can get your API key from the dashboard. In the menu on the left, click API Keys. You’ll see the following page, which is an overview of your keys:

Copy the Live API Key, because you’ll need this for the Flatten PDF API.

Step 3 — Setting Up Folders and Files

Now, create a folder called flatten_pdf and open it in a code editor. For this tutorial, you’ll use VS Code as your primary code editor. Next, create two folders inside flatten_pdf and name them input_documents and processed_documents. Now, copy your PDF file to the input_documents folder and rename it to document.pdf.

Then, in the root folder, flatten_pdf, create a file called processor.js. This is where you’ll keep your code.

Your folder structure will look like this:

flatten_pdf
├── input_documents
|    └── document.pdf
├── processed_documents
└── processor.js

Step 4 — Installing Dependencies

You first need to install the dependencies below:

• axios — This package is used for making REST API calls.

• Form-Data — This package is used for creating form data.

Use the command below to install both of them:

npm install axios
npm install form-data

Step 5 — Writing the Code

Now, open the processor.js file and paste the code below into it:

const axios = require('axios');
const FormData = require('form-data');
const fs = require('fs');

const formData = new FormData();
formData.append(
	'instructions',
	JSON.stringify({
		parts: [
			{
				file: 'document',
			},
		],
		actions: [
			{
				type: 'flatten',
			},
		],
	}),
);
formData.append(
	'document',
	fs.createReadStream('input_documents/document.pdf'),
);
(async () => {
	try {
		const response = await axios.post(
			'https://api.pspdfkit.com/build',
			formData,
			{
				headers: formData.getHeaders({
					Authorization: 'Bearer YOUR_API_KEY_HERE',
				}),
				responseType: 'stream',
			},
		);

		response.data.pipe(
			fs.createWriteStream('processed_documents/result.pdf'),
		);
	} catch (e) {
		const errorString = await streamToString(e.response.data);
		console.log(errorString);
	}
})();

function streamToString(stream) {
	const chunks = [];
	return new Promise((resolve, reject) => {
		stream.on('data', (chunk) => chunks.push(Buffer.from(chunk)));
		stream.on('error', (err) => reject(err));
		stream.on('end', () =>
			resolve(Buffer.concat(chunks).toString('utf8')),
		);
	});
}

ℹ️ Note: Make sure to replace YOUR_API_KEY_HERE with your API key.

Code Explanation

Here you have a FormData variable that contains the instructions for the API. You’re using createReadStream to read the input PDF file. You’re then making the POST request to the Flatten PDF API. The response of the API is stored in the processed_documents folder.

Output

To run the code, use the command below:

node processor.js

On the successful execution of the code, you’ll see a new processed file named result.pdf in the processed_documents folder.

The folder structure will look like this:

flatten_pdf
├── input_documents
|    └── document.pdf
├── processed_documents
|    └── result.pdf
└── processor.js

Final Words

In this post, you learned how to easily and seamlessly flatten PDF files for your JavaScript application using our Flatten PDF API.

You can integrate these functions into your existing applications and flatten PDFs. With the same API token, you can also perform other operations, such as merging documents into a single PDF, adding watermarks, and more. To get started with a free trial, sign up here.
